Skar Audio RP Series 500 Watts Full-Range Class A/B 4 Channel Car Amplifier [‎RP-75.4AB] - Copy

Skar Audio RP-75.4AB Multichannel Amplifier

Class AB 4 Channel Amplifier

4 Way Protection Circuitry: Thermal, Voltage, Speaker, DC

RMS Power @ 2 Ohm: 125 Watts x 4 Channels (14.4v)

RMS Power @ 4 Ohms: 75 Watts x 4 Channels (14.4v)

RMS Power @ 4 Ohms (Bridged): 230 Watts x 2 Channels (14.4v)

MOSFET Power Supply

Soft Turn on Circuit

Tri-Mode Capable / Bridgeable

Frequency Response: 20Hz~20kHz

Signal to Noise Ratio: 105 dB

Low Pass Filter (Variable): 50Hz~500Hz

High Pass Filter (Variable): 20Hz~5kHz

8 Gauge Power and Ground Terminals

Working Voltage: 8.5V-14.4V

Fuse Rating: 60 Amp

Dimensions: 19-1/4" (Length) x 7" (Width) x 3" (Height)

The Skar Audio RP-75.4AB is a powerful, efficient, and highly reliable four channel class a/b full-range car amplifier. Capable of powering an entire aftermarket upgraded speaker system in a vehicle, it packs the power that will allow you to get loud and let your speakers come alive. Featuring a high speed MOSFET power supply, premium grade internal components, as well as 4-way protection circuitry, the amplifier will operate at the highest levels of performance for hours on end safely. With a depth of adjustable user controls such as the Gain, LPF, HPF, Crossover, and Bass EQ, this amplifier is extremely versatile and can be used in so many applications. These advanced user controls will allow you to dial your sound in exactly as you want for perfect clarity, whether running active components or speakers with in-line crossover networks. The class A/B circuitry design of this model allows it to amplify your audio signal with maximum clarity and sound excellence, all while being extremely efficient. Features 8 gauge power and ground input terminal connections for maximum current flow.
